5V 60MM Hand Wheel Pulse Encoder Mill Router Manual Control For CNC System (Black)
Key Words:
Pulse,Encoder§CNC,Pulse,Encoder§Hand,wheel,Pulse,Encoder§Hand,manual,pulse,generator§CNC,Manual,Pulse,Generator
Features:
1、100% brand new and high quality 2、This Pulse Encoder is suitable for manual pulse input type such as CNC or Milling machine 3、High reliability, 6mm terminal connection type, 4、Ultra-thin and lightweight design, metal gear, smooth rotation, no sticking point position 5、Hand wheel 100 stop positions, can return to normal, no high level output
Specification:
Features: 100% brand new and high quality This pulse encoder is suitable for manual pulse input type such as CNC or Milling machine High reliability, 6mm terminal connection type Ultra-thin and lightweight design, metal gear, smooth rotation, no sticking point position Hand wheel 100 stop positions, can return to normal, no high level output Specifications: Material: aviation aluminum Color: black, white (Optional) Product type: 6 terminal Voltage: 5V Diameter: 60mm/2.36in Consumption current: ≤100mA Response frequency :0-20 KHZ Empty ratio: 0.5 T ± 0.1 T Mechanical revolution: 500rpm Normal revolutions: ≤200RPM Protection: oil proof, water-resistance, dustproof IP54 Working temperature: -10~70℃ Working humidity: 30-85% Size: as the picture Weight: 200g Package includes: 1 x CNC Pulse Encoder
Product Image:
Pulse,Encoder§CNC,Pulse,Encoder§Hand,wheel,Pulse,Encoder§Hand,manual,pulse,generator§CNC,Manual,Pulse,Generator
Features:
1、100% brand new and high quality 2、This Pulse Encoder is suitable for manual pulse input type such as CNC or Milling machine 3、High reliability, 6mm terminal connection type, 4、Ultra-thin and lightweight design, metal gear, smooth rotation, no sticking point position 5、Hand wheel 100 stop positions, can return to normal, no high level output
Specification:
Features: 100% brand new and high quality This pulse encoder is suitable for manual pulse input type such as CNC or Milling machine High reliability, 6mm terminal connection type Ultra-thin and lightweight design, metal gear, smooth rotation, no sticking point position Hand wheel 100 stop positions, can return to normal, no high level output Specifications: Material: aviation aluminum Color: black, white (Optional) Product type: 6 terminal Voltage: 5V Diameter: 60mm/2.36in Consumption current: ≤100mA Response frequency :0-20 KHZ Empty ratio: 0.5 T ± 0.1 T Mechanical revolution: 500rpm Normal revolutions: ≤200RPM Protection: oil proof, water-resistance, dustproof IP54 Working temperature: -10~70℃ Working humidity: 30-85% Size: as the picture Weight: 200g Package includes: 1 x CNC Pulse Encoder
Product Image:
